Performance
MIMO 5 GHz - 4 x 4 (DL/UL MU-MIMO)
MIMO 2.4 GHz - 2 x 2 (DL/UL MU-MIMO)
Max. Data Rate 5 GHz - 4.8 Gbps (BW160)
Max. Data Rate 2.4 GHz - 573.5 Mbps (BW40)
Antenna Gain 5 GHz - 5 dBi
Antenna Gain 2.4 GHz - 3 dBi
Max. TX Power 5 GHz - 26 dBm
Max. TX Power 2.4 GHz - 22 dBm
Max. BSSIDs - 8 per Radio
Supported Data Rates 802.11ax (WiFi 6) - 7.3 Mbps to 4.8 Gbps (MCS0 - MCS11 NSS1/2/3/4, HE 20/40/80/160)
Supported Data Rates 802.11ac (WiFi 5) - 6.5 Mbps to 3.4 Gbps (MCS0 - MCS9 NSS1/2/3/4, VHT 20/40/80/160)
Supported Data Rates 802.11n - 6.5 Mbps to 600 Mbps (MCS0 - MCS31, HT 20/40)
