Annapurna Labs Alpine AL324 1.7GHz Quad Core

Processor
AnnapurnaLabs Alpine AL324 ARM® Cortex-A57 4-core 1.7GHz Processor

CPU Architecture
64-bit ARM

System memory
4 GB SODIMM DDR4 (1 x 4 GB)

Maximum memory
16 GB (1 x 16 GB)

Memory slot
1 x SODIMM DDR4

Flash memory
512 MB (dual-boot OS protection)

Drive Bay
5 3.5-inch + 4 2.5-inch SATA 6 Gbps

Drive compatibility
3.5-inch compartments:
3.5-inch SATA hard drives
2.5-inch SATA hard drives
2.5-inch SATA solid-state drives

2.5-inch compartments:
2.5-inch solid-state drives

Hot-swappable
Support for SSD cache acceleration

2.5Gigabit Ethernet Port (2.5G/1G/100M)
2 (2.5G/1G/100M/10m)

10-Gigabit Ethernet port
2 10GbE SFP+ ports

LAN Wake-up (WOL)
2.5GbE port only

Jumbo
Frame

1st Generation USB 3.2 port
3

The shape factor
Tower

LED indicators
System Status, LAN, USB, HDD1~5, SSD1-4

Buttons
Power, Reset, Copy via USB

Dimensions (HxWxD)
176.5×224.6×224.1 mm

Weight (net)
4.66 kg

Gross weight
5.2 kg

Operating Temperature
0–40 °C (32–104 °F)

Storage temperature
-20–70°C (-4–158°F)

Relative humidity
Relative humidity 5-95%, non-condensing, according to a wet thermometer: 27°C (80.6°F)

Power unit
External, 120 W, 100-240 V AC

Power consumption: Hard disk sleep mode
23,833 Watts

Power consumption: operating mode, typical
43,003 Watts

Tested with fully filled disks.

Fan
1 x 140 mm, DC 12V

System warning
Voice prompts or buzzer
