Sensor:1/2.7", progressive scan, 2.0 megapixel, CMOS
Lens: 2.8mm@F2.0
DORI Distance:
-Detect（m）: 46.7
-Observe（m）: 18.7
-Recognize（m）: 9.3
-Identify（m）: 4.7
Angle of View:
horizontal-(H): 112.7°
-Vertical (V): 60.1°
-Diagonal (O): 146.5°
Adjustment angle:
-Pan: 0°~360°
-Tilt: 0°~90°
- Rotate: 0° ~ 360°
Minimum Illumination:
-Colour: 0.02Lux (F2.0, AGC ON)
-0 Lux with IR on
Day/Night:IR-cut filter with auto switch (ICR)
Digital noise reduction:2D/3D
Signal to Noise Ratio (S/N):>52dB
IR Range:Up to 30m (98 ft) IR range
Defog:Digital Defog
Wide Dynamic Range (WDR):Supported
Video Compression: Ultra 265, H.265, H.264, MJPEG
Max. Resolution:1920*1080
H.264 code profile:Baseline profile, Main Profile, High Profile
Frame Rate:1920*1080
Main Stream: 1080P (1920*1080), Max 30fps;
Sub Stream: 720P (1280*720), Max 30fps;
Third Stream: CIF (352*288), Max 30fps
Highlight Compensation (HLC):Supported
Backlight Compensation (BLC):Supported
On-sreen display (OSD):Up to 4 OSDs
Privacy Mask:Up to 8 areas
Region of Interest (ROI):Up to 2 areas
Motion Detection:Up to 4 areas
Behavior Detection:Intrusion, Motion detection,Tampering alarm
Intrusion:Enterandloiterinapre-definedvirtualregion
Protocols: IPv4, IGMP, ICMP, ARP, TCP, UDP, DHCP, RTP, RTSP, RTCP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP, SSL, QoS
Compatible Integration: Integration ONVIF (Profile S, Profile T),API
Network: 10/100M Base-TX Ethernet
Power:12 V DC±25%, PoE (IEEE802.3 af)
Power consumption:Max 4,5W
Dimensions (Ø x H):Φ118 x 96mm
Weight:0.2kg
Working Environment:-30°C ~ +60°C (-22°F ~ 140°F), Humidity:10%~95% RH(non-condensing)
Ingress Protection:IP67
